| The Snap Shot can be easily integrated into a dental unit. |
 |
The wireless hand piece holder can be fixed anywhere and automatically controls the camera light.
Simply unplug the cable and the Snap Shot is easily portable. |
|
SPECIFICATIONS:
- CCD 1/3" High sensitivity
- Resolution: (752x582) PAL ; (768x494) NTSC
- Definition: 470 lines
- Sensitivity: 2 lux
- Lighting: LED
- Adjustments: Automatic
- Non-inverted image
- Angle of view: 80'
- Cable length: 2.5m (Option: 5m)
- Image memory (1 or 4 images in option)
- Size of the hand piece: W:198 ; D:27; H:18mm
- Size of the distal part: D:16.5 x H:12mm
- Weight: 50g
- Power supply: 115V 60Hz or 230V 50Hz
- Power consumption: 12VA or 16VA with memory
- 1 YC S-video output (1 Vcc/75) PAL or NTSC
- CE: conform to the European directive 93/42/CEE
|
